XCSM4102L1; TELEMECANIQUE SENSORS limit switch
Availability:
Out of stock
Limit switch; metal roller Ø11,6mm; NC x2 + NO x2; 1.5A; lead 1m
฿890.00
Out of stock
|
Manufacturer
|
TELEMECANIQUE SENSORS | |
|
Type of sensor
|
limit switch | |
|
Kind of actuator
|
metal roller Ø11,6mm | |
|
Output configuration
|
NC x2 + NO x2 | |
|
Contact current max.
|
1.5A | |
|
Switched voltage
|
max. 250V AC, max. 250V DC | |
|
Connection
|
lead 1m | |
|
IP rating
|
IP68 | |
|
Body dimensions
|
50x30x16mm | |
|
Number of mounting holes
|
2 | |
|
Operating temperature
|
-25…70°C | |
|
Body material
|
metal | |
|
AC contacts rating @R(at resistive load)
at resistive load
|
1.5A / 240V AC | |
|
DC contacts rating @R(at resistive load)
at resistive load
|
0.1A / 250V DC | |
|
Mounting holes pitch
|
20mm | |
|
Switches features
|
snap action contacts | |
|
Trade name
|
PREVENTA |
