XCMD21F2L5; TELEMECANIQUE SENSORS limit switch
Availability:
Out of stock
Limit switch; NO + NC; 6A; max.250VAC; max.250VDC; lead 5m; IP66
฿890.00
Out of stock
|
Manufacturer
|
TELEMECANIQUE SENSORS | |
|
Type of sensor
|
limit switch | |
|
Kind of actuator
|
oblong metal roller Ø10,6mm and additional fixation | |
|
Output configuration
|
NO + NC | |
|
Contact current max.
|
6A | |
|
Switched voltage
|
max. 250V AC, max. 250V DC | |
|
Connection
|
lead 5m | |
|
IP rating
|
IP66 | |
|
Body dimensions
|
30x50x16mm | |
|
Number of mounting holes
|
2 | |
|
Operating temperature
|
-25…70°C | |
|
Body material
|
metal | |
|
Manufacturer series
|
XCMD | |
|
AC contacts rating @R(at resistive load)
at resistive load
|
1.5A / 240V AC | |
|
DC contacts rating @R(at resistive load)
at resistive load
|
1.5A / 24V DC | |
|
Mounting holes pitch
|
20mm | |
|
Switches features
|
snap action contacts | |
|
Design
|
side exit |
